Ref
#
Name of Part Part ID
DynaMax Models
ALL 80 100 150 200 210 250 260 299 399 500 600 700 800
55
Floor Bracket
Left
14-5518-20-25 X X
14-5518 X X X X X X
56
Floor Rear
Bracket
14-5520-20-25 X X
14-5520 X X X X X X X X
57
Top Cover
Assembly
14-5521 X X X X X X X X
58 Dashboard
DASHBOARD
#2
X X X X X X X X
59
Bracket for
Neutralizer Box
14-5525 X X X X X X X X
60 Rubber Bushing 33-0101 X X X X X X X
62
Condensate Pan
Brace
14-5417 X X X X X
63 Cover Plate
14-5421 X X X
14-5421-250 X X
64 Standoff 14-5423 X
66
Electrical Strip
Plate Protector
14-5420 X
67
Air Intake
Adapter
44-0008 X X X X X
68
Plastic Flange
with 3” Street
Elbow
44-0009 X
4” Air Intake Box 14-5551 X X
5” Air Intake Box 14-5546 X
69
3” Air Intake
Adapter
44-0010 X
4” Air Intake
Adapter
14-5559 X X
5” Air Intake
Adapter
14-5556 X
70 Condensate Pan
14
-
5418
X
X
14-5414 X
14-5414-250 X X
71
Condensate Pan
Brace
14-5417 X X X
14-5417-250 X X
72
Plate Heat
Exchanger
Bracket
14-5424 X X X
14-5424-200 X X
73
Transformer
Mounting Plate
14-5541 X X X X X
74 Igniter Gasket GM10-25-018 X
75
Flame Sensor
Gasket
GM10-25-004 X
76
Burner
Refractory
GM10-25-098-01
X X X X X
GM10-25-107-
02
X X X X X X X X
77
Automatic Air
Vent
FV-4M1 X
78 Terminal Board TB-001.001 X
79 On/Off Switch
C6000ALBBXCHLI
X
