Camus Hydronics DynaMax DMH081 - PART 15 ELECTRICAL DIAGRAMS (Continued); Field Wiring Guide; System Sensor and Cascade Wiring

80
Ref
#
Name of Part Part ID
DynaMax Models
ALL 80 100 150 200 210 250 260 299 399 500 600 700 800
80
40VA
Transformer
HCT-
01E0BB06
X
81
Supply/Return
Sensor
NTC-
SENSOR-002
X
82 Flue Sensor
NTC-
SENSOR-003
X
83 Outdoor Sensor
NTC-
SENSOR-004
X
84 Sensor Wire
CABLE
HARNESS
X
85 DHW Sensor
NTC-
SENSOR-001
X
86 Gas Valve Elbow
45900400-132/B
X X X X X X X
45900400-144/B
X X
87
Gas Valve Wire
Harness
45900441-015B
X X X
45900429-007B
X X X X X X
88 Relief Valve
10-407-05 X X X X X X X
10-604-10 X X X
89 Wiring Harness
77-0004 X X X X X
77-0006 X X X X X X X X
90 Firing Valve
USA0509101T X X X X X X X
13105 X X
13106 X X X X
91
DynaMax Fan
Discharge Orifice
14-0377-80 X X
14-0377-100 X
14-0377-250 X X
92
Expandable Air
Inlet Adapter w/o
Pressure Test
Point
14-0378 X X X X X
93
Expandable Air
Inlet Adapter
1056-22 X X X X X
94 Flex Pipe
2" Diameter X X X X X X X X X
3" Diameter X
4” Diameter X X
5” Diameter X
95
Flexible Stainless
Steel Pipe 1" X 11"
66-0075 X
96
Flexible Stainless
Steel Pipe 1/2" X 11"
66-0073 X
97
Manual Shutoff
Valve Kit
50002653-001 X
98
Rear Vent
Adapter
GM10-15-991-01
X X
GM10-15-992-01
X X X
99 Metal Latch
6521-00-0551-YT
X X X X X X X X
100 Strike 7800-02 X X X X X X X X
101 Interface Module 848IF X
