Camus Hydronics DynaMax DMH081 - PART 15 ELECTRICAL DIAGRAMS (Continued); Detailed Connector Descriptions

81
Ref
#
Name of Part Part ID
DynaMax Models
ALL 80 100 150 200 210 250 260 299 399 500 600 700 800
102
Plastic to
Stainless Steel
Vent Adapter
300566 X X X X X X X
300611 X X X
Stainless to
Plastic Vent
Adapter
FS0604PVCR X
300537 X X
103
Rubber Air
Sleeve
1056-22 X X X X X X X X X
1056-33 X
1056-44 X X
1056-55 X
104 Burner Gasket
GM10-25-074-09
X X X X X X X X X X
GM10-35-078-03
X X X
105
Fan Gasket/
Mixing Chamber
Gasket
33-0036 X X X X X X X
33-0037 X X X X X X X X X
33-0038 X
33-0043 X X X
33-0057 X X X
106 Air Inlet Gasket 33-0069 X X X
107
Current
Transformer
(Combination
Models only)
RIBXRA X
Not shown in Exploded View
Part Recommended spare parts
