MAINTENANCE PROCEDURES
NO TICE
It is not recommended to
blow compressed air on the paper
element; this could damage the pa-
per fibers and reduce its filtration
ability when used in dusty environ-
ments. If engine air filter is too dirty
and cannot be cleaned following the
recommended procedure, it should
be replaced.
Useacleandampclothtowipeboth
thefiltersealingsurfaceandtheinside
of the outl et tube . En su re that t he out-
let tube sealing area is undamage d.
Inspect air filter housing for cleanli-
ness.
Duckbill Valve Cleaning
Visually c hec k and physically s queeze
the duckbill valve. Make sure the valve
is flexible and not inverted, damaged
or plugged.
Engine Air Filter Installation
Insert the filter c a refully. Sea t the filter
by hand, ma k ing c erta in it is ins erted
completely into the air c le aner hous-
ing. Apply pressure by hand a t the
outer rim of the filter, not the flexible
center.
Secure air filter cover with latches.
219002066-017
RH SIDE OF VEHICLE, U ND E R CARG O BOX
1. Air filter cover
2. Latches
CVT Air Filter
CVT air filter inspection and cleaning
frequency should be adjusted accord-
ing to riding conditions as it is critical
to e nsure proper engine performance
and life span.
CVT Air filter inspection and cleaning
frequency m us t be increa s ed for the
following sev ere ridin g c onditions:
– Riding on dry sand.
– Riding on dry dirt covered surfaces.
– Riding on dry gravel trails or similar
conditions.
– Riding in areas with high concentra-
tion of seeds or crop husks.
– R iding in severe snow condition s.
NOTE: Riding in a group in these con-
ditions wo uld increase even more the
air filter replacement requi rement.
CVT Air Filter Removal
1. Tilt ca rgo bo x.
2. Press the filter tabs to release it.
tmr2016-106-101_a
1. Press here
CVT Air Filter Inspection and
Cleaning
1. In sp ect filter and replace if dam-
aged.
2. C lean filter, using a solution of soft
soap and water, then rinse it.
3. Gently shake off excess water and
allow filter to dry at room tempera-
ture.
