MAINTENANCE PROCEDURES
Place vehicle on a level surface.
Place a drain pan under the engi ne
drainplugarea.
Open cargo box .
Clean the drain plug area.
Unscrew drain plug and discard the
gasket ring.
tmr2011-010-003_a
1. Gasket ring
2. Drain plug
Remove the dipstick.
Allow oil to drain completely from the
crankcase.
Clean the m a gnetic drain plug from
metal shav ings a nd residue. Presence
of debris gives an indication of interna l
engine da m a ge.
Install a NEW gasket ring on the drain
plug.
NO TICE
Never use the gasket ring
a second time. Always replace by a
new one.
Install and tighten drain plug to the rec -
ommended spec ification.
TIGHTENING TORQUE
Drain plug
30 N•m ± 2 N•m
(22lbf•ft ± 1lbf•ft)
Replace oil filter. Refer to
OIL FILTER
.
Refill engine with recomm ended en-
gine oil.
For eng ine oi l capa c ity, refer to
SPECI-
FICATIONS
.
Oil Filter
Oil Filter Access
Open cargo box .
Remove pass enger seats and engine
service cover if nee ded.
Oil Filter Removal
Clean oil filter area.
Remov e oil filter cover.
Remove oil filter.
tmr2011-010-004_a
TYP ICAL
1. Oil filter scr ew
2. Oil filter cover
3. O-ring
4. Oil fil ter
Oil Filter Installation
Check and c lean the oil filter inlet a nd
outlet are a for d irt a nd other conta mi-
nations.
vmr2015-008-003_a
1. Inlet bore from the oil pump to the oil filter
2. O utlet bore to th e en gin e oi l pro vi di ng
system
