MAINTENANCE PROCEDURES
MASTER FUSE BOX
(INSIDE FRONT STORAGE CENTER)
NO DESCRIPTION RATING
F10 T vehicle 10 A
F11 Headl amps 20 A
F12
DC1/DC3/12V
accessory outlet 1
10 A
F14
12 V Accessory
outlet 2
10 A
F16 Tail lamps 10 A
R3
ECM/Accessory 12V
-
R8 Brake lights
-
R9
Accessory post
12V/outlet 2
-
Spare
1
Spare 20 A
SECONDARY FUSE BOX
(UNDER PASSENGER SEAT)
NO DESCRIPTION RATING
F4 Cluster/relays 10 A
F5
Ignition/injection/fuel
pump
10 A
F6
Engine Control
Module (ECM)
10 A
F7 4WD actuator 10 A
F8
Ignition switch
Clock
10 A
F9 Cooling fan 25 A
F18
Oxygen sensor
Emission control
10 A
R1
Cooling fan
-
R2 Main
-
R10 Air conditioning
-
SECONDARY FUSE BOX
(UNDER PASSENGER SEAT)
NO DESCRIPTION RATING
Spare
1
Spare
10 A
Spare
2
Spare 10 A
Spare
3
Spare
10 A
FUSE BOX #5
(INSIDE FRONT STORAGE CENTER)
NO DESCRIPTION RATING
F1 Fan speed relays 20 A
F3 Air conditioning rel ay 5 A
RLS
Fan speed relay - low
-
RMS
Fan speed relay -
medium
-
RHS
Fan speed relay
-high
-
FUSE LINKS
FUSE
LINK
DESCRIPTION RATING
1Main18awg
2 Accessory post
14 awg
REGULATOR FUSE HOLDER
NO DESCRIPTION RATING
-
Regulator 50 A
Lights
Headlight Bulb Replacement
NO TICE
Never touch glass portion
of a halogen bulb with bare fingers,
it shortens its operating life. If glass
is touched, clean it with isopropyl al-
cohol which will not leave a film on
the bulb.
