EQUIPMENT
tmo2016-010-073_a
SECU RING TOOL BOX IN PLACE
Removing Tool Box
To remove tool box, unlock it by lifting
handle.
tmo2016-010-071_b
UNLOCK ING REMOVA BLE TOOL BOX
WARNING
Before riding, always make sure
tool box is secured to vehicle and
lid is locked.
Under seat Storage Box (If
Equipped)
A convenient rem ov a ble under sea t
storage box is ava ilable .
tmo2016-010-074_b
TYP ICAL
1. Under seat st orage box
To re m ov e under seat storage box, lift
RH passenger seat and r em ov e un der
seat storage box by pulling it upwards.
tmo2016-010-074_a
TYP ICAL
NOTE: When reinstalling under sea t
storage box, mak e su re to align it prop-
erly with seat tubes and floor em bos s
so i t fits p roperly under the seat.
Open Storage Compartments
Multiple ope n storage compartments
are av ailable in the cons ole.
WARNING
When riding vehicle, make sure no
object stored in open storage com-
partments could cause harm in the
event of a roll over.
90
