Canon imagePROGRAF iPF6400 User Manual

3 Select the printer in the A Printer list.
4
Click Manage Custom Sizes in the F Paper Size list to
display the Custom Page Sizes dialog box.
5 Double-click Untitled in the list at left, and then enter a name for the page size you want to register. Here, en-
ter 100*500.
If the Untitled size is not listed at left, click + below the list.
6 Under Page Size, enter 10 in Width and 50 in Height. Here, measurements are entered in centimeters.
7 Specify the margins by entering 0.3 in Printer Margins. Here, too, measurements are entered in centimeters.
8 Click OK to close the Custom Page Sizes dialog box.
9 In the F Paper Size list, click the size of the original. In this case, click 100*500, the size you registered.
10 In G Orientation, click the icon of the document in landscape orientation.
11 Click OK to close the dialog box.
Print the banner
Follow the steps below to print the banner using the corresponding banner settings.
1 Choose Print in the application menu.
iPF6400 Printing Vertical or Horizontal Banners (Large-Format Printing; Mac OS X)
User's Guide
Enhanced Printing Options Printing banners or at other non-standard sizes
115

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
