Canon imagePROGRAF iPF6400 User Manual

Loading Rolls in the Printer
Loading Rolls in the Printer
Follow these steps to load rolls in the printer.
Important
• Always load rolls when the printer is on. If the printer is off when you load a roll, the paper may not be advanced correctly
when you turn the printer on.
• Before loading a roll, confirm whether the inside of the Top Cover or the Ejection Guide is soiled. If soiled, we recommend
cleaning in advance. (See "Cleaning Inside the Top Cover.") →P.861
→User's Guide (HTML)
1
Press the Load button.
2 Press ▲ or ▼ to select Roll Paper, and then press the OK button.
Note
• If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press ▲ or ▼ to select "Yes", and then press the OK button. Remove the paper and go to the next step.
3
Open the Roll Feed Unit Cover.
4
Holding the Roll Holder flange (a), load the Roll Holder
shaft into the guide grooves (b) on both sides of the
Roll Holder Slot. At this time, load the shaft so that the
color of the Roll Holder shaft (c) matches the color of
the guide groove.
Loading Rolls in the Printer iPF6400
User's Guide
Handling and Use of Paper Handling rolls
534

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
