Auto Arrange Spacing
Change the object-to-object spacing to be applied in the operation of laying out objects automatically.
Note
You can input between 0.0 and 100.0(mm) (between 0.00 and 3.94(inch)).
You can change the numbers by clicking either button or button.
Page Setup Dialog Box
Page Setup Dialog Box
This dialog box appears when you select Page Setup from the File menu.This dialog box provides selections for set-
ting the media size, orientation and other important features.
Paper Orientation
This selects the paper orientation.
The following settings are available for orientation.
Setting Details
Vertical Prints the image and text created with the application software in the orientation as it is.
Horizontal Prints the image and text by rotating sideways 90 degrees from the orientation as specified in the
application.
Roll Paper Length
Set the length of one page to print on roll paper.
When you place a checkmark on Auto Settings, the one-page length to be printed on roll paper is automatically
set so that the laid-out objects are printed on one page.
Note
Available only if rolls are selected in Paper Source.
You can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
You can change the numbers by clicking either button or button.
Order
Set the object layout order.
The following settings are available for order.
Setting Details
Upper Left to Right The objects are laid out from upper left to right.
Upper Left to Bottom The objects are laid out from upper left to bottom.
Page Setup Dialog Box (Mac OS X)
iPF6400
User's Guide
Mac OS X Software Free Layout
434
