Preferences Dialog Box
Preferences Dialog Box
This dialog box appears when you select Preferences from the imagePROGRAF Advanced Preview menu. You can
set the preferences for Free Layout.
•
Units
Set the unit for paper length, margins, and so on.
• Gridlines
You can input a grid line width value in numerical characters so that they serve as a guide to laying out objects.
Note
• You can input between 10.0 and 200.0(mm) (between 0.39 and 7.87(inch)).
• You can change the numbers by clicking either ▲ button or ▼ button.
• Divisions
You can change the number of divisions of grid lines so that they serve as a guide to laying out objects.
Note
• You can input between 1 and 10.
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Grid Color
Select the grid line color.
•
Print Object Frames
You can print the object border.
Note
• If you do not want to print the object border, deselect the Print Object Frames check box.
•
Object Frame Style
You can select the object frame style for printing.
The following settings are available for the object frame style.
Setting Details
Solid Line You can print the solid line as the frame style.
Dotted Line You can print the dotted line as the frame style.
Dashed Line You can print the dashed line as the frame style.
iPF6400
Preferences Dialog Box (Mac OS X)
User's Guide
Mac OS X Software Free Layout
433
