Canon imagePROGRAF iPF6400 User Manual

Setting Details
Crop Marks You can print with the crop marks.
Page Options Dialog Box
Page Options Dialog Box
This dialog box appears when you select Page Options from the File menu. This allows you to configure the roll paper
length, object layout order, and margins of Free Layout.
•
Roll Paper Length
Set the length of one page to print on roll paper.
The following settings are available for roll paper length.
Setting Details
Auto Settings The one-page length to be printed on roll paper is automatically set so that the laid-out objects
are printed on one page.
Manual Settings You can input the length of one page to print on roll paper in numerical characters.
Note
• Available only if rolls are selected in Paper Source.
• You can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Order
Set the object layout order.
The following settings are available for order.
Setting Details
Upper Left to Right The objects are laid out from upper left to right.
Upper Left to Bottom The objects are laid out from upper left to bottom.
Upper Right to Left The objects are laid out from upper right to left.
Lower Left to Top The objects are laid out from lower left to top.
iPF6400
Page Options Dialog Box (Windows)
User's Guide
Windows Software Free Layout
223

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
