Canon imagePROGRAF iPF6400 User Manual

• Support Information button
Click the button to display websites that contain the latest product information.
Note
• An Internet connection is needed to view the websites.
• User Manual button
Click the button to display the printer manuals installed on the computer.
Note
• You must have User Manual installed on your computer.
•
About button
Click the button to open the version information window of the Print Plug-In. Click the OK button in the version
information window to return to the Print Plug-In window.
Adjustment pattern setting dialog box
Adjustment pattern setting dialog box
Displays the adjustment pattern by taking images with the adjustment values varying up and down in steps from the
baseline adjustment values in the Color Settings sheet (color or monochrome). This allows you to print the adjustment
pattern and select your preferred adjustment values while comparing the images.
• Preview Area
This area allows you to view adjustment pattern images side-by-side to check the state when changes to adjust-
ment values are applied.
The adjustment values of the image enclosed in the blue frame in the center are used as the base values, with
images arranged around this with the adjustment values varying in steps up and down from these base values. If
you click any of the images, the adjustment pattern is redisplayed with the adjustment values from that image as
the base values.
The adjustment values are displayed at the top of each image. If both the Horizontal Axis and Vertical Axis are
configured, the adjustment value for the Horizontal Axis is displayed on the right and the adjustment value for the
Vertical Axis is displayed on the left. If the image is so small that the adjustment values cannot be displayed, you
can check the adjustment values by displaying the tool tip.
Note
• For images where the adjustment values are out of range, an adjustment pattern is not displayed and the message Out
of Range is displayed instead.
Adjustment pattern setting dialog box iPF6400
User's Guide
Mac OS X Software Print Plug-In for Photoshop / Digital Photo Professional
478

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
