Canon imagePROGRAF iPF6400 User Manual

• Document: Any Type
• Page Size: A square sheet (430 × 430 mm [16.9 × 16.9 in])
• Paper: Sheets
• Media Type: Any type
• Paper Size: A square sheet (430 × 430 mm [16.9 × 16.9 in])
Note
• The following procedures are based on Mac OS X v10.5. The method of setting up non-standard paper sizes varies depend-
ing on the version of Mac OS X.
1 Create the document in the application.
2 Load the square paper (430 × 430 mm [16.9 × 16.9 in]) in the printer.
3
Choose Print in the application menu.
4 Select the printer in the A Printer list.
5
Click Manage Custom Sizes in the F Paper Size list to
display the Custom Page Sizes dialog box.
6 In Page Size, enter the height and width of the original. Here, enter 43.00 cm in Height and Width.
7 In Printer Margins, enter 0.5 for the top and side margins and 2.3 for the bottom margin. Here, measurements
are entered in centimeters.
8 Double-click Untitled in the list at left in the Custom Page Sizes dialog box and enter the paper name—in this
case, 430*430.
9 Click OK to close the Custom Page Sizes dialog box.
10 In the F Paper Size list, click the size of the original. In this case, click 430*430, the size you registered.
Printing on Non-Standard Paper Sizes (Mac OS X) iPF6400
User's Guide
Enhanced Printing Options Printing banners or at other non-standard sizes
120

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
