Canon imagePROGRAF iPF6400 User Manual

Note
• When the objects are not selected, you can not select Format.
• Rotate
When you place a checkmark here, you can select Rotate Right or Rotate Left.
Setting Details
Rotate Right Rotates the object 90 degrees clockwise.
Rotate Left Rotates the object 90 degrees counterclockwise.
Note
• When several objects are selected, you cannot select Rotate.
•
Enl./Red.
When you place a checkmark here, you can select Scaling, Fit Paper Size, or Fit Photo Size.
Setting Details
Scaling Allows you to input the value of the enlargement or reduction ratio of an object.
Fit Paper Size Prints by enlarging or reducing each object to match the paper size. If you are using roll paper,
objects are enlarged or reduced so that the width of each object matches the width of the roll
paper.
Fit Photo Size Prints all of the objects at the specified photo size.
Note
• You can input between 25 and 600.
• You can change the numbers by clicking either ▲ button or ▼ button.
Position
Sheet
You can rotate, enlarge, or reduce an object.
Note
• When the objects are not selected, you can not select Format.
iPF6400 Format Dialog Box (Windows)
User's Guide
Windows Software Free Layout
225

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
