Canon imagePROGRAF iPF6400 User Manual

6
Load the custom paper in the printer and then click the
OK button.
Important
• Do not load paper that is curled or that has already been printed on.
7
The Step 3: Paper Source Settings dialog box is dis-
played. Select the paper source where the custom pa-
per is loaded and then click the OK button.
8
The Step 4: Paper feed adjustment dialog box is dis-
played. Click the Execute button to execute paper feed
adjustment.
The adjustment pattern is printed, and the paper feed is
automatically adjusted based on the printing result.
Once the paper feed adjustment is complete, click the
Next button.
Important
• Check that there is no paper left on the ejection guide.
• If Paper Feed Adjustment is not executed, horizontal stripes with different color tones may appear in the printed
material. Paper feed adjustment does not need to be executed more than once. Execute paper feed adjustment
only once each time you add a custom paper.
9 The Roll Paper Settings dialog box is displayed.
Note
• If a paper source other than Roll Paper is selected in the Step 3: Paper Source Settings dialog box, this screen is
not displayed.
iPF6400 Add Custom Paper (Windows)
User's Guide
Handling and Use of Paper Media Configuration Tool (Windows)
585

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
