Chapter 18
18-18
F-18-30
4) Click [OK] after downloading is completed.
F-18-31
5) Turn OFF and back ON the main power.
Never turn OFF the power of the machine while the machine executes writing. If the power is turned OFF at this time, the writing is interrupted, and the
machine fails to start up as a result.
When the machine does not start up, format BOOTDEV using the HD format, and then download System, Language, and RUI.
6) Turn OFF and back ON the main power according to the screen on the control panel.
18.4.5 Downloading KEY
18.4.5.1 Outline
0008-9221
iR105i/iR105+ / iR9070 / iR85+ / iR8070
KEY is in common among the models that have the new iR controller, and is registered under "iRXXXX" on the SST.
KEY has 2 types (XXxc and XXxp). Be sure to download both types.
18.4.5.2 Downloading Procedure
0008-9219
iR105i/iR105+ / iR9070 / iR85+ / iR8070
MEMO:
Download mode is available in both normal mode (press 1+7) and safe mode (press 2+8).
To Next Page
