Chapter 17
17-1
17.1 Outline
17.1.1 Construction of Service Mode(iR105)
0007-0318
iR105
The service mode screens are arranged in a 3-level construction: Initial screen, Level 1/2 screen, Level 3 screen.
F-17-1
The machine' s service mode consists of the following 7 types:
F-17-2
17.1.2 Service mode screen configuration
0008-7886
iR105i/iR105+ / iR9070 / iR8070
As shown below, the service modes use three screen levels: initial screen -> main/intermediate item screen -> sub-item screen.
One set of modes are used for normal maintenance (Level 1 modes), and another set are used for troubleshooting (Level 2 modes).
Initial screen
Level 1/2
screen
Level 3 screen Level 3 screen Level 3 screen
User screen
From Level
1/2 screen
Reset key
Previous/
Next page
Previous/
Next page
Previous/
Next page
( )(2,8)( )
Reset key
Level 1 item selected at screen top
Level 2 item selected from list
Level 3 screen
Item selected
COPIER
FEEDER
SORTER
BOARD
DISPLAY
I/O
ADJUST
FUNCTION
OPTION
TEST
COUNTER
Control display mode
Input/output display mode
Adjustment mode
Operation/inspection mode
Settings mode
Test print mode
Counter mode
