Chapter 15
15-24
F-15-15
T-15-7
15.3.2 Motor
15.3.2.1 Motors
0007-0934
iR105i/iR105+ / iR9070
Name Notation
Fixing web solenoid SL2
Delivery flapper solenoid SL3
Fixing/feeder unit locking solenoid SL4
Manual feed pickup latch solenoid SL6
Deck (right) pickup solenoid SL7
Deck (left) pickup solenoid SL8
Cassette 3 pickup solenoid SL9
Cassette 4 pickup solenoid SL10
Reversing flapper solenoid SL11
SL9
SL10
SL7
SL8
SL6
SL11
SL3
SL4
SL2
