1.2.2.6 Cross Section
0008-7335
/ iR8070
[1] Fixing assembly [20] Right deck pickup roller
[2] Fixing web [21] Right deck feeding roller
[3] Laser unit [22] Right deck separation roller
[4] Feeding assembly [23] Right deck
[5] Drum cleaner assembly [24] Cassette 3 pickup roller
[6] Photosensitive drum [25] Cassette 3 feeding roller
[7] Primary charging assembly [26] Cassette 3 separation roller
[8] Bending mirror [27] Cassette 4 pickup roller
[9] Toner cartridge [28] Cassette 4 feeding roller
[10] Hopper [29] Cassette 4 separation roller
[11] Developing cylinder [30] Cassette 4
[12] Pre-transfer charging assembly [31] Cassette 3
[13] Manual feed feeding roller [32] Left deck
[14] Manual feed pick roller [33] Left deck separation roller
[15] Manual feed separation roller [34] Left deck feeding roller
[16] Pre-transfer exposure LED [35] Left deck pickup roller
[17] Registration roller [36] Fixing lower roller
[18] Transfer charging assembly [37] Fixing upper roller
[19] Separate charging assembly [38] External delivery roller
