Chapter 9
9-37
9.8 Duplex Feeding Unit
9.8.1 Copying on the First Side
0007-0463
iR105i/iR105+ / iR9070 / iR8070
F-9-42
9.8.2 Printing on the First Side
0008-8989
iR85+
DC controller PCB
J509-A2
Registration paper detection signal (PS5S)
Delivery flapper solenoid drive signal (SL3D)
J508-B18
Lower feeder motor
PS16
PS12
PS5
Reversal motor
M11
PS6
PS10
[1]
[2]
[3]
[1]
[2]
[3]
PS9
SL3
SL11
M12
J519-B5
Reversing flapper solenoid drive signal (SL11D)
J508-A8 J508-A5
J508-A11
Fixing/feeding outlet paper
detection signal (PS11S)
External delivery detection signal (PS10S)
Reversal paper detection signal (PS16S)
J508-B15
J508-A2 J519-B6
Fixing separation claw paper detection signal (PS6S)
Internal delivery detection signal (PS9S)
Duplexing reversal detection paper signal (PS12S)
PS11
