Canon ImageRunner iR8500 Series User Manual

Chapter 1
1-19
F-1-19
[39] ADF
[40] Right deck
[41] Cassette 4
[42] Cassette 3
[43] Left deck
1.2.2.8 External Covers
0008-8220
Those covers that can be detached by mere removal of mounting screws are omitted from the discussions (number of screws indicated).
F-1-20
[1] Card Reader Case
[2] ADF
[3] Upper right cover
[4] Right rear cover
[5] Waste toner cover (1 screw)
[6] Manual feed tray unit
[7] Upper vertical path cover
[8] Right lower cover
[9] Lower vertical path cover
[10] Right deck
[11] Cassette 4
[12] Cassette 3
[13] Left deck
[14] Front cover
[39]
[40]
[41]
[42]
[43]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[1]
