1.7.1.3 Electric Parts
0016-8168
iPF6100 / iPF6200 / iPF6000S
The electric parts of the printer are activated when the printer is connected to the AC power supply.
At the left rear of the printer are the main controller, power supply, and interface connector. The carriage PCB is incorporated in the carriage unit, and the operation
panel is on the upper right top cover.
When serving the printer with the cover removed, be extremely careful to avoid electric shock and shorting electrical devices.
F-1-57
1.7.1.4 Electric Parts
0024-8354
iPF6300 / iPF6350 / iPF6300S
The electric parts of the printer are activated when the printer is connected to the AC power supply.
At the left rear of the printer are the main controller, power supply, and interface connector. The carriage PCB is incorporated in the carriage unit, and the operation
panel is on the upper right top cover.
When serving the printer with the cover removed, be extremely careful to avoid electric shock and shorting electrical devices.
F-1-58
Carriage PCB
Operation panel
Interface connector
Main controller
Power connectorPower supply
Carriage PCB
Interface connector
Main controller
Power connectorPower supply
Operation panel
