Chapter 1
1-18
1.3.2 Product Specifications
0020-1815
iPF6200
Printable area (Roll media) Area excluding 3mm from the leading edge, 3 mm from the trailing edge,
and 3 mm from the left and right edges.
Borderless printing: 0 mm from the leading edge, trailing edge, and left
and right edges.
Width of media allowing borderless printing:
10"(254mm), B4(257mm), A3+(329mm), 14"(356mm), 16"(407mm),
A2(420mm), A2+/17"(432mm), B2(515mm), A1(594mm),
24"(610mm)
Media type allowing borderless printing:
Premium Coated Paper, Heavyweight Coated Paper, Extra Heavyweight
Coated Paper, Premium Matte Paper, Glossy Photographic Paper
190gsm, Satin Photographic Paper 190gsm, Glossy Photographic Paper
240gsm, Satin Photographic Paper 240gsm, HW Glossy Photo Paper,
HW Satin Photo Paper, Premium RC Photo Luster, Glossy Photo Paper,
Semi-Glossy Photo Paper, Heavyweight Glossy Photo Paper 2,
Heavywght SemiGlos Photo Paper 2, Poster Semi-Glossy Photo Paper,
Fine Art Photo, Fine Art Heavyweight Photo, Fine Art Textured, Fine
Art Watercolor, Fine Art Block Print
Printable area (Cut sheet) Area excluding 3 mm from the leading edge, 3 mm from the trailing edge
(23 mm when supplied from manual feed from top or selected the fine
art), and 3 mm from the left and right edges.
Printing recommendation area
(Roll media)
Area excluding 20 mm from leading edge, 5 mm from the trailing edge
and 5 mm from the left and right edges (standard size).
Printing recommendation area
(Cut sheet)
Area excluding 20 mm from the leading edge, 27 mm from the trailing
edge, and 5 mm from the left and right edges (standard size).
Memory 384MB
Increase of memory: none
Firmware Flash ROM (update from USB or Ethernet, IEEE1394)
- Printer description language
GARO (Graphic Arts language with Raster Operation)
Interface USB2.0, Ethernet, IEEE1394 (option)
Operation panel LCD (160 X 128 dots), 12 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean, Russianand
and Japanese
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead [PF-03] Number nozzles: 2560 nozzles per color
Ink tank [PFI-103]MBK,BK,GY,PGY
[PFI-101]R,G,B,C,M,Y,PC,PM
Capacity: 130 ml per color (Ink tanks supplied with the printer contain
90 ml of each color.)
Detection functions (Cover
system)
Detects opening/closing of the top cover and ink tank cover.
Detection functions (Ink passage
system)
Detects presence/absence of ink tank, ink level (dot count and electrode),
presence/absence of the maintenance cartridge, waste ink full level,
presence/absence of the printhead, and opening/closing of the supply
valve.
Detection functions (Carriage
system)
Detects the ambient temperature, head temperature, presence/absence of
the head, and no ink ejection.
Detection functions (Paper path
system)
Detects presence/absence of paper, cutter position, leading/trailing edge
of paper, paper width, and skew.
Operating noise During printing: Approx. 49 dB (A) or less
During standby: Approx. 35 dB (A) or less
Operating environment Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80% without dew condensation
Print quality guaranteed
environment
Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH
Power supply 100-120 VAC (50/60 Hz), 220-240 VAC (50/60 Hz)
Power consumption (Maximum) During printing: Max. 100 W
Power consumption In power save (sleep) mode: 5W or less(220-240 VAC: 6W or less)
(When IEEE1394 board installed, 8W or less[220-240 VAC: 9W or
less])
During standby: 1 W or less
Printer unit dimensions
(WxDxH)
1177 x 670 x 344 mm
With stand (option): 1177 x 870 x 991 mm
Weight Approx. 51 kg
Type Bubble jet large-sized paper printer
Feeding system Automatic feeding of one roll media/One cut sheet (manual feed from
front)/One cut sheet (manual feed from top)
