Canon iPF6100 - Carriage

Chapter 1
1-45
1.5.11 Carriage
0016-8157
iPF6100 / iPF6200 / iPF6000S / iPF6300 / iPF6350 / iPF6300S
F-1-45
[1] Printhead lock cover
This cover is used to lock the printhead. Open this cover when installing the printhead.
[2] Printhead
The printhead incorporated nozzles. It is an important part for printing.
[3] Printhead lock lever
This lever is used to lock the printhead. Open this lever when installing the printhead.
[4] Wire guide
This stay is used as an ink tube guide.
[4]
[2]
[1]
[3]
[2]
