Chapter 4
4-2
4.2 Disassembly/Reassembly
4.2.1 Disassembly/Reassembly
0016-9450
iPF6100 / iPF6200 / iPF6000S / iPF6300 / iPF6350 / iPF6300S
For the procedure for disassembly/reassembly of the components excluding the major components, refer to the parts catalog.
Illustrations in the parts catalog are assigned illustration numbers according to the order in which parts are disassembled.
4.3 Points to Note on Disassembly and Reassembly
4.3.1 Note: Items that should never be disassembled
0012-6349
iPF6100 / iPF6200 / iPF6000S / iPF6300 / iPF6350 / iPF6300S
Assemblies that should never be removed after initial factory adjustments, are indicated by the presence of red screws.
Under no circumstance should these red screws be loosened or removed. Removing these screws will render the printer out of alignment forever.
F-4-2
4.3.2 Moving the carriage manually
0012-6350
iPF6100 / iPF6200 / iPF6000S / iPF6300 / iPF6350 / iPF6300S
Move the carriage as required during disassembly/reassembly to prevent the carriage form contacting the parts to be removed.
The carriage does not move when capped. When uncapping moving the carriage, refer to the procedures in DISASSEMBLY/REASSEMBLY>Points to Note on
Disassembly and Reassembly>Opening the Cap/Moving the Wiper Unit.
4.3.3 Units requiring draining of ink
0012-6351
iPF6100 / iPF6200 / iPF6000S / iPF6300 / iPF6350 / iPF6300S
