Chapter 3
3-1
3.1 Installation
3.1.1 Making Pre-Checks
3.1.1.1 Making Pre-Checks
0016-8483
iPF6100 / iPF6200 / iPF6000S
Package dimensions and weight are as follows.
Main body (with a palette): 1320 (W) mm x 914 (D) mm x 645 (H) mm, Approx. 79 kg
F-3-1
Installation space
Main body only: 1477 (W) mm x 1770 (D) mm x 648 (H) mm
Main body with stand: 1477 (W) mm x 1961 (D) mm x 1293 (H) mm
When printing from the Front Paper Feed Slot, leave at least 1,300 mm (51.2 in) of unobstructed space in front of the printer and 700 mm (27.6 in) behind it.
3.1.2 Unpacking and Installation
3.1.2.1 Unpacking and Installation
0016-8530
iPF6100 / iPF6200 / iPF6000S
The printer must be moved with it held by three or more persons on both sides. Be careful not to get your lower back and other regions hurt.
F-3-2
+300mm
+300mm
+800mm
+150mm
+150mm
