7.1.13 Sample Printout
0016-9412
iPF6100 / iPF6200 / iPF6000S
a) PRINTINF
A sample printout that is produced by executing [SERVICE MODE] > [DISPLAY] > [PRINTINF] is shown below, along with instructions about how to interpret it.
F-7-41
(1) Version numbers of the firmware installed in the printer, boot ROM, and MIT DB format
(2) Printer information
For more item details, see "Detail of Service Mode" > "a) Display".
(3) Counter information
For more item details, see "Detail of Service Mode" > "e) Counter".
(a) Consumables status
(b) Number of days elapsed since the counter was last reset
(c) Counter value
(d) Value with which consumables reach their replacement timing
(e) Ratio of the current count to the replacement timing
(f) Cumulative counter value
(4) History of execution of color calibration
(a) Order of the date of execution
When the value becomes larger, the date becomes older.
(b) Date of execution
(c) Operation executed
0: Automatic Restore Default with Head Replacement
1: Replace Multisensor
2: General Adj.
3: Restore Default
xxxx PRINT INF
Firm:00.49 Boot:00.31 MIT(DBF):9303 MIT(DB):1.02 S/N:DF029090
SYSTEM
TYPE:DF029090 24 0 TMP:26 SIZE_LF: 0.0 SIZE_CR: 514.3
HEAD S/N R:39410000 L:04400000 HEAD LOT R:166L09A0 L:166L09A0
INK
Y :0 PC :0 C :0 PGY :0 GY :0 BK :0
PM :0 M :0 MBK :0 R :0 G :0 B :0
WARNING
01:0000 02:0000 03:0000 04:0000 05:0000
06:0000 07:0000 08:0000 09:0000 10:0000
11:0000 12:0000 13:0000 14:0000 15:0000
16:0000 17:0000 18:0000 19:0000 20:0000
ERROR
01:03060A00-2E01 02:0000 03:0000 04:0000 05:0000
06:0000 07:0000 08:0000 09:0000 10:0000
11:0000 12:0000 13:0000 14:0000 15:0000
16:0000 17:0000 18:0000 19:0000 20:0000
INK CHK: Y:0 PC:0 C:0 PGY:0 GY:0 BK:0 PM:0 M:0 MBK:0 R:0 G:0 B:0
COUNTER
PRINTER
LIFE TTL:0 LIFE ROLL:0 LIFE CUTSHEET:0
LIFE A:0 B:0 C:0 D:0 E:0 F:0
POWER ON:0 CUTTER:1 WIPE:6 W-INK:79%
MEDIA 7 MEDIA OTHER
NAME : NAME : OTHER
TTL : 0.0 m2 0.0 sq.f TTL : 0.0 m2 0.0 sq.f
ROLL : 0.0 m2 0.0 sq.f ROLL : 0.0 m2 0.0 sq.f
CUTSHEET : 0.0 m2 0.0 sq.f CUTSHEET : 0.0 m2 0.0 sq.f
PARTS COUNTER
COUNTER A : OK 36
PARTS A1 : 0.0 36.1 0% 0.0
COUNTER B : OK 36
PARTS B1 : 0.0 64.0 0% 0.0
COUNTER D : OK 36
PARTS D1 1362 13028571 0% 1362
PARTS D2 : 377 6700000 0% 377
PARTS D3 : 2238 16500000 0% 2238
PARTS D4 : 33 60000 0% 33
PARTS D5 : 2238 16500000 0% 2238
COUNTER F : OK 36
PARTS F1 : 377 4000000 0% 377
COUNTER H : OK 36
PARTS H1 : 15 50000 0% 15
COUNTER L : OK 36
PARTS L1 : 4 12500 0% 4
COUNTER P : OK 36
PARTS P1 : 0 750 0% 0
COUNTER R : OK 36
PARTS R1 : 0 27500 0% 0
COUNTER V : OK 36
PARTS V1 : 0.0 15.2 0% 0.0
COUNTER X : OK 36
PARTS X1 : ----- -------- 0% -----
PV AUTO JUDGE : ON(NORMAL) , 1
Calibration History (Last 20times)
Date Action Media Temp[C]/Humid[%]
1: 2007/02/24 0
2: 2007/02/24 0
3: 2007/02/24 0
4: 2007/02/24 0
5: 2007/02/24 0
6: 2007/02/22 3
7: 2007/02/21 2 Matte Photo 27/ 40
8: 2007/02/20 0
9: 2007/02/15 3
10: 2007/02/15 2 Special 1 20/ 59
11: 2007/02/15 2 Special 1 20/ 58
12: 2007/02/15 2 Special 1 20/ 57
13: 2007/02/15 2 Special 1 20/ 56
14: 2007/02/15 2 Special 1 20/ 55
15: 2007/02/15 2 Special 1 20/ 54
16: 2007/02/15 2 Special 1 20/ 53
17: 2007/02/15 2 Special 1 20/ 52
18: 2007/02/15 2 Special 1 20/ 51
19: 2007/02/15 2 Special 1 20/ 50
20: 2007/02/02 2 Glossy Photo 27/ 38
(1)
(2)
(3)
(a) (b) (c) (d) (e) (f)
(5)
(a) (b)
(a) (b) (c) (d) (e)
(4)
To Next Page
