Chapter 1
1-26
1.3.6 Product Specifications
0026-6422
iPF6300S
Firmware Flash ROM (update from USB or Ethernet)
- Printer description language
GARO (Graphic Arts language with Raster Operation)
Interface USB2.0, Ethernet
Operation panel LCD (160 X 128 dots), 13 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean, Russianand
and Japanese
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead [PF-05] Number nozzles: 2560 nozzles per color
Ink tank [PFI-105]MBK, BK, C, M, Y, PC, PM, GY, PGY, R, G,B
Capacity: 130 ml per color (Ink tanks supplied with the printer contain
90 ml of each color.)
Detection functions (Cover
system)
Detects opening/closing of the top cover and ink tank cover.
Detection functions (Ink passage
system)
Detects presence/absence of ink tank, ink level (dot count and electrode),
presence/absence of the maintenance cartridge, waste ink full level, and
opening/closing of the supply valve.
Detection functions (Carriage
system)
Detects the carriage position, presence/absence of the printhead, height
of the printhead, the ambient temperature, head temperature, and no ink
ejection.
Detection functions (Paper path
system)
Detects presence/absence of paper, leading/trailing edge of paper, paper
width, skew, cutter position, height of the cutter, height of the spur,
rotation of the feed roller.
Operating noise During printing: Approx. 47 dB (A) or less
During standby: Approx. 35 dB (A) or less
Operating environment Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80% without dew condensation
Print quality guaranteed
environment
Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH
Power supply 100-120 VAC (50/60 Hz), 220-240 VAC (50/60 Hz)
Power consumption (Maximum) During printing: Max. 100 W
Power consumption In power save (sleep) mode: 6W or less(220-240 VAC: 7W or less)
During standby: 1 W or less
Printer unit dimensions
(WxDxH)
1177 x 670 x 344 mm
With stand (option): 1177 x 870 x 991 mm
Weight Approx. 51 kg
Type Bubble jet large-sized paper printer
Feeding system Automatic feeding of one roll media/One cut sheet (manual feed from
front)/One cut sheet (manual feed from top)
Feeding capacity - Roll media
One roll at the back/Outer diameter of roll: 150 mm or less/Inner
diameter of paper tube: 2 or 3 inches
- Cut sheet
1 sheet
Delivery method Delivers the media with its printed side up in the forward direction.
Sheet delivery capability Using the stand (option) basket:
- Roll media
1 sheet
- Cut sheet
1 sheet
Cutter Automatically cuts paper laterally. Cartridge-type (with round blade)
