Chapter 5
5-2
5.2.2 Consumable Parts
0020-7346
iPF6000S
T-5-3
After supplies have been replaced, execute [INITIALIZE] > [PARTS COUNTER] > [PARTS xx] in service mode to initialize (clear) the parts counter information.
Consumables Service Mode
Name Part number Q'ty
Life sheets/
A1
PARTS xx COUNTER x States (Error Code)
Service SUCTION FAN UNIT QM3-0701-000 1 15000 A1 A OK/W1/E146-4001
DUCT UNIT, PLATEN QM3-0800-000 1 15000 B1 B OK/W1/E146-4001
CARRIAGE UNIT QM3-0784-000 1 15000 D1 D OK/W1/W2
LEVER, R, INK TUBE QC2-0659-050 1 15000
LEVER, L, INK TUBE QC2-0660-050 1 15000
LINK, LEVER, TUBE QC2-0661-000 4 15000
SPRING, TENSION QC2-1396-000 2 15000
PAD, OIL QC2-0664-000 2 15000
HOLDER, WIRE(MECH) QC2-0663-000 1 15000
TUBE GUIDE UNIT QM3-0704-000 1 15000
CLEANING UNIT, R, RAIL,
CARRIAGE
QM3-0543-000 1 15000 D1/D3
CLEANING UNIT, L, RAIL,
CARRIAGE
QM3-0542-000 1 15000
FLEXIBLE CABLE ASS'Y QM3-0786-000 1 15000 D2
ENCODER SENSOR UNIT QM2-3421-000 1 15000 D3
SCALE, LINEAR QC2-0696-000 1 15000
CAM, LIFTER QC2-0675-000 2 15000 D4
MULTI SENSOR UNIT QM3-0365-000 1 15000 D5
X1 X OK/W1/W2
INK SUPPLY UNIT QM3-5295-000 1 15000 F1 F OK/W1/E144-4047
INK SUPPLY UNIT (R) QM3-5294-000 1 15000
INK TUBE UNIT (L) QM3-5295-000 1 15000
INK TUBE UNIT (R) QM3-5296-000 1 15000
PURGE KIT QM3-0654-040 1 15000 H1 H OK/W1/E141-4046
HEAD MANAGEMENT SENSOR QM3-0529-000 1 15000 L1 L OK/W1/E194-404A
MOTOR, 26.4V, DC QK1-0447-000 1 15000 P1 P OK/W1/W2
MIST FAN UNIT QM3-0807-000 1 15000 V1 V OK/W1/E146-4001
MIST FILTER UNIT QM3-0212-030 1 15000
User See "Product Overview> Features> Consumables"
