8) Wipe off dirt inside the top cover with a cloth moistened with water and then wrung tight. Wipe off ink smears from the entire surface of the platen,
the pinch roller unit, borderless printing ink grooves, blue switch and all else that is accessible.
F-5-17
- Do not dry the interiors of the top cover with a dry cloth. Electrostatic charges could make the internal components susceptible to dirt, resulting in de-
graded print quality.
- Do not use flammable solvents, such as thinner and benzine, on the printer. Solvents coming into contact with any electrical parts inside the printer could
result in fires or electrical shock hazards.
- Do not touch linear scale [1] and carriage shaft [2].
F-5-18
9) Close the top cover.
[1][2]
