Canon iPF6100 - Page 443

Chapter 6
6-19
T-6-17
T-6-18
25 GND - GND
26 GND - GND
27 GND - GND
28 GND - GND
29 GND - GND
30 GND - GND
J3411 (Temperature/humidity detection sensor)
Pin Number Signal name IN/OUT Function
1 TH2_OUT IN Thermistor output signal
2 GND - GND
3 RHV_OUT IN Temperature/humidity detection sensor output signal
4 SNS_5V Power supply (+5V)
J3501 (Carriage PCB J12)
Pin Number Signal name IN/OUT Function
1 GND - GND
2 GND - GND
3 H-DASH LICC2 B OUT Analogue switch A/D trigger signal
4 GND - GND
5 H0-D-DATA-7-OD OUT Odd head R data signal 7(D)
6 GND - GND
7 H0-E-HE-8 OUT Head R heat enable signal 8(E)
8 GND - GND
9 H0-E-DATA-8-OD OUT Odd head R data signal 8(E)
10 GND - GND
11 H0-F-DATA-10-OD OUT Odd head R data signal 10(F)
12 GND - GND
13 H0-E-DATA-9-OD OUT Odd head R data signal 9(E)
14 GND - GND
15 H0-F-HE-10 OUT Head R heat enable signal 10(F)
16 GND - GND
17 H0-F-DATA-11-OD OUT Odd head R data signal 11(F)
18 GND - GND
19 H0-F-HE-11 OUT Head R heat enable signal 11(F)
20 GND - GND
21 H0-F-DATA-11-EV OUT Even head R data signal 11(F)
22 GND - GND
23 H0-F-DATA-10-EV OUT Even head R data signal 10(F)
24 GND - GND
25 H0-E-HE-9 OUT Head R heat enable signal 9(E)
26 GND - GND
27 H0-E-DATA-9-EV OUT Even head R data signal 9(E)
28 GND - GND
29 GND - GND
30 GND - GND
31 GND - GND
32 GND - GND
33 GND - GND
34 GND - GND
35 H0-A-DATA-0-OD OUT Odd head R data signal 0(A)
36 GND - GND
37 H0-A-DATA-1-OD OUT Odd head R data signal 1(A)
38 GND - GND
39 H0-B-HE-2 OUT Head R heat enable signal 2(B)
40 GND - GND
41 H0-B-DATA-2-OD OUT Odd head R data signal 2(B)
J3402 (Carriage PCB J21)
Pin Number Signal name IN/OUT Function
