b) I/O DISPLAY
The status of each sensor and switch is shown in the display.
Sensor and switch status is shown in the display.
ON = 1
OFF or not used = 0
Screen 1
T-7-61
Screen 2
T-7-62
Screens 1 and 2 are selectable with the [ ] and [ ] buttons.
These screens display the associated sensor status as listed in the table below.
T-7-63
I / O D I S P L A Y 1 Upper row
0000000000000000Lower row
12345678910111213141516(Display position)
I / O D I S P L A Y 2 Upper row
0000000000000000Lower row
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 (Display position)
Display
position
Sensor name LCD display contents
1 Pump Cam Sensor 0: Sensor ON , 1: Sensor OFF
2 Valve Open/Closed Detection Sensor 0: Sensor ON , 1: Sensor OFF
3 (Not Used) -
4 (Not Used) -
5 Spur Cam Sensor 0: Sensor ON , 1: Sensor OFF
6 Lift Cam Sensor 0: Sensor ON , 1: Sensor OFF
7 Feed Roller HP Sensor 0: Sensor ON , 1: Sensor OFF
8 Top Cover Sensor 0: Cover open , 1: Cover close
9 (Not Used) -
10 Ink Tank Cover Switch 0: Cover open , 1: Cover close
11 (Not Used) -
12 Paper Detection Sensor 0: Sensor ON , 1: Sensor OFF
13 (Not Used) -
14 (Not Used) -
15 (Not Used) -
16 (Not Used) -
17 Roll Media Sensor 0: Sensor ON , 1: Sensor OFF
18 Roll Cam Sensor 0: Sensor ON , 1: Sensor OFF
19 (Not Used) -
20 Cutter Right Position Sensor 0: Sensor ON , 1: Sensor OFF
21 Cutter HP Sensor 0: Sensor ON , 1: Sensor OFF
22 (Not Used) -
23 (Not Used) -
24 (Not Used) -
25 (Not Used) -
26 Roll unit detection 0: Roll unit not detected , 1: Roll unit detected
27 (Not Used) -
28 (Not Used) -
29 (Not Used) -
30 (Not Used) -
31 (Not Used) -
32 (Not Used) -
