Chapter 7
7-78
6) CR MOTOR COG
Adjust the carriage motor rotation.
Perform in the following cases:
- When removing/attaching or replacing the carriage or carriage belt.
- When replacing the carriage motor or linear encoder sensor.
- When there is excessive load on the carriage (such as when jamming)
If the following error message appears when performing CR MOTOR COG, check that carriage and carriage belt are installed properly and clean the rail shaft. If
the error still occurs, replace the carriage motor.
F-7-28
7) SPUR CLEANING
If white dots appear about 1mm apart in the paper feed direction, clean the spur.
Set a cleaning sheet and clean the spur following the instructions displayed on the screen.
- Do not fold the cleaning sheet.
- Do not use a cleaning sheet with rugged edges or a significantly folded cleaning sheet.
- If the cleaning sheet is warped, flatten it before use.
ERROR
CR V I BRAT I ON
