Chapter 7
7-83
4) CLEAR: Counters related to counter initialization
T-7-160
5) EXCHANGE: Counters related to parts replacement
T-7-161
Display Description Unit Remarks
CLR-INK CONSUME Cumulative count of ink section consumption amount clearing Times
CLR-MTC EXC. Cumulative count of maintenance cartridge replacement count clearing Times
CLR-HEAD L EXC. Cumulative count of printhead L replacement count clearing Times
CLR-HEAD R EXC. Cumulative count of printhead R replacement count clearing Times
CLR Wia-1 EXC. Cumulative count of unit Wia-1(suction fan) replacement count clearing Times
CLR Wib-1 EXC. Cumulative count of unit Wib-1(platen duct) replacement count clearing Times
CLR CR-1 EXC. Cumulative count of unit CR-1(carriage unit bushing) replacement count
clearing
Times
CLR CR-2 EXC. Cumulative count of unit CR-2(fexible cable unit) replacement count clearing Times
CLR CR-3 EXC. Cumulative count of unit CR-3(linear encoder sensor/linear scale/shaft cleaner)
replacement count clearing
Times
CLR CR-4 EXC. Cumulative count of unit CR-4(carriage height changing cam) replacement
count clearing
Times
CLR CR-5 EXC. Cumulative count of unit CR-5(multi sensor) replacement count clearing Times
CLR SP-1 EXC. Cumulative count of unit SP-1(ink tube unit) replacement count clearing Times
CLR PG-1 EXC. Cumulative count of unit PG-1(purge unit) replacement count clearing Times
CLR HMa-1 EXC. Cumulative count of unit HMa-1(head management sensor) replacement count
clearing
Times
CLR PL-1 EXC. Cumulative count of unit PL-1(feed motor) replacement count clearing Times
CLR PS-1 EXC. Cumulative count of unit PS-1(spur) replacement count clearing Times
CLR Mi-1 EXC. Cumulative count of unit Mi-1(mist fan/mist filter) replacement count clearing Times
CLR MS-1 EXC. Cumulative count of unit MS-1(multi sensor) replacement count clearing Times Calibration error index, This counter
synchronizes with CLR CR-5 EXC.
CLR CT-1 EXC. Cumulative count of unit CT-1(cutter) replacement count clearing Times
CLR-FACTORY CNT. For factory Times
Display Description Unit
MTC EXC. Maintenance cartridge replacement count Times
HEAD L EXC. Printhead L replacement count Times
HEAD R EXC. Printhead R replacement count Times
BOARD EXC.(M/B) Main controller PCB replacement count Times
Wia-1 EXC. Wia-1(suction fan) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Wia-1])
Times
Wib-1 EXC. Wib-1(platen duct) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Wib-1])
Times
CR-1 EXC. CR-1(carriage unit bushing) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-1])
Times
CR-2 EXC. CR-2(fexible cable unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-2])
Times
CR-3 EXC. CR-3(linear encoder sensor/linear scale/shaft cleaner) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-3])
Times
CR-4 EXC. CR-4(carriage height changing cam) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-4])
Times
CR-5 EXC. CR-5(multi sensor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-5])
Times
SP-1 EXC. SP-1(ink tube unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS SP-1])
Times
PG-1 EXC. PG-1(purge unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS PG-1])
Times
HMa-1 EXC. HMa-1(head management sensor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS HMa-1])
Times
PL-1 EXC. PL-1(feed motor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS PL-1])
Times
PS-1 EXC. PS-1(spur) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS PS-1])
Times
Mi-1 EXC. Mi-1(mist fan/mist filter) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Mi-1])
Times
MS-1 EXC. MS-1(multi sensor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS MS-1])
Times
CT-1 EXC. CT-1(cutter) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CT-1])
Times
