31
(23) Information Display
Information, such as the frame rate, camera pan/tilt/zoom values and descriptions of each function, is shown in
the Information Display.
Warning and error messages will also be displayed here if there are problems with camera operations or
systems.
For details on the information displayed, refer to “List of Viewer Messages” (P. 179).
(24) Pan/Tilt Slider
Drag the slider to pan (horizontally) or tilt (vertically) the camera (P. 36).
(25) Zoom Slider
Drag the slider to operate the zoom in (telephoto)/zoom out (wide-angle) function of the camera (P. 36).
(26) Preset Selection Menu
Selects a preset registered in the camera in advance (P. 41).
(27) [Home Position] Button
Moves the camera angle to the home position (P. 41).
• The (4) [Reconnect] button, (19) [Main] Menu, and (23) Information Display are available even if all authorized user and
guest user privileges are disabled on the Settings page.
• When [Video] > [Picture (Option)] > [Camera Control] > [Image Stabilizer] (P. 75) on the Settings page is set to on, the actual
angle of view of the video will be smaller than the zoom values shown in the Information Display.
