Capstone Turbine Corporation • 16640 Stagg Street • Van Nuys • CA 91406 • USA
Installation Guide: Capstone C1000S/C800S/C600S with C1000 Series Controller
480064 Rev C (December 2018) Page 55 of 122
Capstone reserves the right to change or modify, without notice, the design, specifications, and/or contents of this document without
incurring any obligation either with respect to equipment previously sold or in the process of construction.
The preferred means of isolation is to install a gate or butterfly valve to isolate individual exhaust
ducts from the common header. Gate valves can provide a zero leakage seal and be operated
while the other turbines are running.
An acceptable means of isolation is to include a flanged joint in the exhaust duct as a location to
install a blind plate during long term non-operation. Blinding operations cannot be performed while
exhaust duct is still hot. Be aware that heat from operational turbines may limit the ability to install
blind during operation.
