3-CONTROLSANDINSTRUMENTS

Loaderbucketoatcontrol

Withtheleverinposition(3),thebucketfollowsthecon-

toursofthegroundwithoutitbeingnecessarytooperate

thelever.

NOTE:Inthispositiontheleverdoesnotautomatically

returntoneutralwhenitisreleased.Itisnecessaryto

moveitmanually.

LEEN11T0092AA4

Fillingtheloaderbucket

Withtheleverinposition(4),thebucketrollsback(lls).

LEEN11T0096AA5

Dumpingtheloaderbucket

Withtheleverinposition(5),thebucketrollsforward

(dumps).

LEEN11T0097AA6

3-52
