Case 695ST - Transmission Controls

3-CONTROLSANDINSTRUMENTS
Transmissioncontrols
WARNING
Lossofcontrolhazard!
Topreventinadvertentmachinemovement,takecaretoavoidaccidentalcontactwiththegearshift
levers.Alwaysstoptheengine,rmlyapplytheparkingbrake,andplaceallgearshiftleversinneutral
beforeleavingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0130A
Powershuttletransmissioncontrols(580ST-590ST)
LEEN11T0017FA1
1.Gearshiftlever:
•
Itispossibletoselectfourforwardandfourrearward
travelgearswiththislever.
2.Transmissiondisconnectbutton(ongearshiftlever):
•
Priortogearshifting,pressandholdthisswitch,se-
lectthedesiredgearwiththegearshiftleverandre-
leasetheswitchtoreengagetransmission.
3.Directionoftravellever:
•
Themovementofthisleverfromtheneutralposition
willengagetheforwardorreversetravel.
NOTE:Thewarninghornactivatesinreversetravel.
4.Hornbutton
5.Transmissiondisconnectbutton(onloaderattach-
mentcontrollever).
