9-SPECIFICATIONS
Dimensionsandperformance
Dimensions-2WSsideshift
LEEN11T0020FA1
Fronttires
12.5/80-18I3
Reartires18.4-26R4
Standardloaderbucket1(35.3ft³)
Standardbackhoebucket914mm(36.0in)
A
Overallmachinelength5865mm(230.9in)
BLoaderbucketreach
2060mm(81.1in)
C
Wheelbase
2175mm(85.6in)
DBackhoebucketdimensions
1630mm(64.2in)
E
Rearwheelbase-backhoeattachmentswingaxis
1325mm(52.2in)
Machinemaximumheight(upperpartofbackhoe)
NOTE:Applicableto580T/580STwithanin-linecylinderboom.
4000mm(157in)
F
Machinemaximumheight(upperpartofbackhoe)
NOTE:Applicableto580T/580STwithanoverlappingcylinderboomand590ST.
3780mm(149in)
GStabilizerwidth
2430mm(95.7in)
H
Cabheight2950mm(116.1in)
ILoaderbucketwidth
2250mm(88.6in)
