Case 695ST - Cab Air Louvers

3-CONTROLSANDINSTRUMENTS
Cabairlouvers
Airowdiffusersareconnectedtotheheatersystemand
receiveairfromtheblower,todirectwarmorcoldaironto
thewindshieldandsidewindowsortothecabinterioras
required.
Eachdiffusermaybeswivelledandadjustedtocontrolthe
owofair.
Toopenadiffuser,pressonesideofthediscandturnit,
asrequired,todirecttheairow.
Thediffusersarelocatedasfollows:
•
Twoonthetopofthefrontcontrolpanels(A);
•
Twototherearoftheseat(C);
•
Twoundertheseat,oneinfront,theotherontherear
(D);
•
Twoonthecabposts,rightandleft(B);
•
Twoontheceiling,infrontandbackofoperator’shead
(E).
NOTE:Thediffusers(B)and(E)aremountedonly
whenair-conditioningsystem(optional)istted.
