7-MAINTENANCE

Alternator

NOTICE:Donotusesteamcleaningdevicesnorcleaningsolventstocleanthealternator.

Havethealternator(1)checkedbyyourDealer.

LEEN12T0474AA1

Startermotor-Check

Havethestartermotor(2)checkedbyyourDealer.

NOTE:Makesuretheterminalprotectorsarecorrectlyin-

stalled.

7-95
