3-CONTROLSANDINSTRUMENTS

Loaderattachment–Operation

Neutralandhold

Withtheleverintheneutral/holdposition0,theattach-

mentmovementcanbestopped.Assoonastheleveris

released,itautomaticallyreturnstotheneutralposition0

andtheattachmentremainsinthepositionwhereitwas

whenmovementstopped.

LEEN11T0089AA1

Raisingtheloaderattachment

Withtheleverinposition(1),theattachmentrises.

LEEN11T0090AA2

Loweringtheloaderattachment

Withtheleverinposition(2),theattachmentlowers.

LEEN11T0091AA3

3-51
