Case 695ST - Power Shuttle Transmission - Oil Filter Replacement

7-MAINTENANCE
Powershuttletransmission-Oillterreplacement
1.Movethemachinetoalevelandrmground.
2.Raisetheloaderattachmentandinstallthesafetysup-
portstrut.
3.Placethebackhoeattachmentintheroadtravelposi-
tion.
4.Placethedirection-of-travelleverandgearshiftleverin
neutralposition.
5.Immobilizethemachinewiththeparkingbrake.
6.Stoptheengineandremovethestarterswitchkey.
7.Openandraisetheengineguard.
LEEN11T0354AA1
8.Cleantheareaaroundthelterhead.
9.Placeacontainerwithsuitablecapacityunderthelter
(1).
10.Loosenandremovethecartridge.
11.Applyathinlayerofoilonthenewlterseal.
12.Assemblethenewcartridge(1).Manuallyscrewin
thecartridgeuntilthesealtouchesthelterhead.
13.Tightenby2/3ofaturn.
NOTICE:Overtighteningcandamagethelterseal.
LEEN11T0405AA2
14.Removethedipstick(1)andtopuptheoilthroughthe
dipstickhole.Thenrestorethedipstick(1)intoplace.
15.Checktheoillevelwiththedipstickand,ifnecessary,
addmoreoil.
16.Lowerandlocktheengineguard.
17.Removethesafetysupportstrutandlowertheloader
attachment.
RAIL15TLB0174AA3
Oilspecicationandcapacities
UseCASEAKCELAHY-TRAN®ULTRACTION(MAT
3525).
Capacities:
•
2WD:18.5L(4.89USgal)
•
4WD:20.8L(5.49USgal)
7-77
