Case 695ST - Hydraulic Hoses, Tubes, and Fittings

7-MAINTENANCE
Hydraulichoses,tubes,andttings
WARNING
Hotliquidunderpressure!
Ifleaksaredetectedinthehydraulichoses,tubes,orttingsduringtheinspection,carryoutthe
followingbeforeyouperformanymaintenanceactivities:
1.Stoptheengine.
2.Releasethehydraulicsystempressure.
Failuretocomplycouldresultindeathorseriousinjury.
W1334A
Checkthehydraulicsystemlinesforpossibleleaks.
Repairallhydraulicoilleakspromptlytoavoidlossof
oilandpossibledamageanddirtentryintothesystem.
Whencheckingforhydraulicleaks,startandoperate
theengineat1200-1500RPM.
Removeandinstallnewhosesimmediately,iftheyare
severelydamagedbyacutorscrape,swollenatthe
ttings,orleaking.
Ifyoureplaceahydraulichoseortube,usethefollowing
procedure:
1.Loosenthettings(1)andremovethehoseortube,
thenremoveanddiscardtheO-ringseal(2).
ImmersethenewO-ringintocleanhydraulicoilbefore
assembly.
2.InstallthenewO-ring(2)intothetting(1)andifnec-
essary,retaininpositionusingPETROLEUMJELLY.As-
semblethenewhoseortubeandtightenthettingn-
ger-tight,whileholdingthetubeorhosetopreventit
fromturning.Thetube’sorhose’sturningcoulddam-
agetheO-ring.
3.Usingtwosuitablewrenches,tightenthettingsto
specication.
NOTICE:Whenreplacingorassemblingapipeorhose,
makesurethatallelementsareperfectlycleanandfree
fromanytraceofdirt.Failuretoensureabsolutecleanli-
nesswillresultinthehose/pipeleakingafterinstallationor
possibledamagetootherhydraulicsystemcomponents.
LEEN11T0359AA1
Toensurealeakfreejointisobtained,itisimportant
thatthettingsarenotovertorquedorundertorqued.
Whenreplacingahose,itisnecessarytobleedairfrom
thesystem.Forthispurpose,lettheenginerunat1200
-1500RPM,contemporarilyactuatingtheloaderand
backhoeattachmentcontrolsfor15minoruntilairis
bledfromthesystem.
LEEN11T0360AA2
7-19
