Case 695ST - Seat Suspension and Rails

To Next Page

To Previous Page

7-MAINTENANCE

Seatsuspensionandrails-greasing

Wipeallmovingpartswithacleanclothandapplya

lightcoatofspraydrylubricant.

MOLI12LBB0351AA1

7-43
