Case 695ST - Transmission Oil Level

7-MAINTENANCE
Transmissionoillevel
NOTICE:Checktheoillevelwiththeenginerunningatlowspeedandatnormaloperatingtemperature.
1.Movethemachinetoalevelandrmground.
2.Raisetheloaderattachmentandinstallthesafetysup-
portstrut.
3.Placethebackhoeattachmentintheroadtravelposi-
tion.
4.Placethedirection-of-travelleverandgearshiftleverin
neutralposition.
5.Immobilizethemachinewiththeparkingbrake.
6.Stoptheengineandremovethestarterswitchkey.
7.Openandraisetheengineguard.
8.Insertthestarterswitchkeyandrestarttheengineby
keepingitatlowidle.
LEEN11T0354AA1
9.Extractthedipstick(1),cleanitwithacleanclothand
completelyinsertitintothehose,thentakeitoutagain.
10.Iftheoillevelisbelowtheminimummark,topup.
11.Stoptheengine.
12.Lowerandlocktheengineguard.
13.Removethesafetysupportstrutandlowertheloader
attachment.
RAIL15TLB0174AA2
OilspecicationandCapacities
UseCASEAKCELAHY-TRAN®ULTRACTION(MAT
3525).
Capacities
•
Machineswithpowershuttletransmission(2WD):
18.5L(4.89USgal)
•
Machineswithpowershuttletransmission(4WD):
20.8L(5.49USgal)
•
Machineswithpowershifttransmission:20.8L
(5.49USgal)
7-50
