Case 695ST - Backhoe Bucket - Installation

6-WORKINGOPERATIONS
Backhoebucket-Installation
Mechanicalcoupler
NOTE:Onlyapplicabletomodelswithanoverlapping
cylinderboom.
1.Starttheengine.
2.Movethemachinesothatyoucaneasilyviewand
accessthebucketwiththebackhoe.
3.Lowerthestabilizers.
4.Slowlymovetheendofthedipperarmbetweenthe
bucketlugspayingattentionthatthemechanicalcou-
plerhook(2)engagesthebucketpin(1).
NOTE:Makesurethatthebucketdoesnotrotateoff
themechanicalcouplerwhenmaneuveringtheback-
hoecylinders.
5.Raisetheboomandadjustthebucketcylinderuntil
theholeonthedipperarm(3)alignswiththeholein
bucketopening(4).
RCPH10TLB397AAF1
6.Stoptheengineandremovethestarterswitchkey.
7.CAUTION
Flyingobjects!
Weareyeprotection.Donotstrikesteelpartswith
asteelhammer.Partsmaybreak.
Failuretocomplycouldresultinminorormoder-
ateinjury.
C0024A
Insertpin(3).
8.Securethepositionofthepin(3)withwashers(2)and
thesnaprings(1).
9.Carefullyoperatethebackhoecontrolstoconrmthe
bucketdoesnotdisconnectfromthedipper.
LEEN11T0192AA2
6-35
