Backhoeattachmentauxiliaryhydraulictools
WARNING
Equipmentfailurecouldcauseaccidentorinjury!
Useonlyauthorizedauxiliaryhydraulicattachments.Alwaysreadandunderstandthemanualorin-
structionssuppliedbythemanufacturertoavoidinjuryordamage.Understandtheoperationand
safetyinstructionsbeforeyouattach,remove,oroperatetheattachment.
Failuretocomplycouldresultindeathorseriousinjury.
W0231A
Beforeusingauxiliarytools(3),itismandatoryto
proceedasfollows:
1.Placethedirection-of-travelcontrollevertoneutral
position.
2.Placethegearshiftleverintheneutralposition.
3.Lowertheloaderattachmenttotheground.
4.Positionthebackhoesothatyoumayeasilymake
anyrequiredconnections.
5.Applytheparkingbraketopreventthemachinefrom
moving.
6.Shutdowntheengine,releaseallpressureinthe
auxiliarycircuit.
7.Removetheauxiliaryhoseplugsandconnectthetool
hosestothecouplings(1)attheendoftheboom.
8.Starttheengineandplacetheacceleratorknob/lever
infullspeedposition.
9.Pressdownthecontrolpedal(2)tooperatethetool.
10.Releasethecontrolpedal(2)tostopthetool.
LEEN11T0285BA1
Flowselection
Itisuptotheoperatortodecidewhichowshould
beusedbyconsultingthemanufacturer’soperating
instructions.Makesuretorespecttheprescribed
delivery.Excessowcandamagesomeequipment.
1.Ifnecessary,adjusttheowregulatoronthechassis
infrontoftherearaxle.ConsultyourDealerforassis-
tance.
LEEN11T0286AA2
