Case 695ST - Every 50 Hours; Fuel Pre-Filter - Draining Condensation (580 ST; 590 ST; 695 ST); Fuel Pre-Filter - Draining Condensation

7-MAINTENANCE
Every50hours
Fuelpre-lter-drainingcondensation(580ST/590ST/695ST)
WARNING
Firehazard!Avoidinjuryand/ormachinedamage!
Duringmaintenanceactivities,makesurethatthehigh-pressurefuellinesarenotdamaged.Afuel
leakfromthehigh-pressurefuellinescancauseanaccidentand/orseriouspersonalinjury.Ifthefuel
linesaredamaged,contactyourdealerimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W1335A
1.Movethemachinetoalevelandrmground.
2.Raisetheloaderattachmentandengagethesafety
strut.
3.Placethebackhoeattachmentintheroadtravelposi-
tion.
4.Placethedirection-of-travelleverandgearshiftleverin
neutralposition.
5.Engagetheparkingbrake.
6.Stoptheengineandremovethestarterswitchkey.
7.Waitthetimenecessarytoallowtheengineandthefuel
systemtocooldown.
LEEN11T0354AA1
8.Opentheenginecompartmenthood.
9.Placeacontainerunderthelter.Drainthewaterand
sedimentsfromthefuellter(1)throughthedraining
valve(2)
•
Fromthebottomofthelter,removetheconnector
(2).
•
Installa1m(3ft)longdraintubeontothedraining
valveandputtheotherendofthetubeintothecon-
tainer.
•
Loosenthedrainingvalveabouttwoturns.Assoon
ascleanfuelexitsthedraintubeclosethedraining
valve.
•
Tightenthedrainingvalve.Donotovertightenthe
drainvalve.
•
Bleedairfromthefuelsystem,see7-101.
NOTE:Thedrainingintervalcanbeincreasedorde-
creased,dependingonthepresenceofwaterandthe
quantityoffuel.
LEIL13TLB0001BA2
7-31
